SMT-55A

Product Line: SMT-55A

LVD: EN61010-1:2010 EN61010-2-033:2012 EN61010-031:2015

EMC: EN 61326-1:2013, EN 61326-2-1:2013

OTHER:

  • Product description
  • parameter
  • Product parameters
  • Analogue Multimeter

    DC/AC Voltage, DC/AC Current, Resistance

    Continuity check, battery test ,dB test, AC/DC shift

    Safety category :CATⅢ500V

  •

    Analogue Multimeter SMT-55A
    Specification Range Accuacy
    DC Voltage 100m/2/10/50/100/250/500V ±4%  of FS
    AC Voltage 10/50/250/500V ±5%  of FS
    DC Current 0.05m/0.5m/5m/10m/50m/100m/500m/10A ±4% of FS
    AC Current 0.25m/2.5m/25m/50m/250m/500mA ±5%  of FS
    Resistance R×1/R×10/R×100/R×1KΩ   Max. 10MΩ
    ±4% of arc
    Feature
    Continuity check <40Ω beeper sounds
    Battery Test 9V & 1.5V
    dB test -8~+56dB on ACV ranges
    AC/DC shift  Slide switch
    General Characteristic
    Power AAX2
    Product Size 150x102x54mm
    Product Net weight 326g
    Standard Accessories
    Battery,Test leads,Manual,Blister Card
    Safety Rating CATⅢ 500V
