SCM-40C
Digital Clamp Meter, 4000 Count LCD Display Test DC/AC Voltage,AC Current,Resistance
Product Line: SCM-40C
LVD: EN 61010-1:2010, EN 61010-2-633:2012, EN 601010-031:2015
EMC: EN61010-2-030:2016 EN 61326-2-1:2013
OTHER:
- Product description
- parameter
- Product parameters
-
Digital Clamp Meter, 4000 Count LCD DisplayTest DC/AC Voltage,AC Current,ResistanceDiode Test,Continuity,Low Battery Indicator,Auto Range,Data Hold,Auto Power offJaw Size:≥22mm;Max Conductor Size:≥21mm
-
-
-
Digital Clamp Multimeter SCM-40D Specification Range Accuacy DC Voltage 4/40/400/600V ±(0.8%+5)AC Voltage 4/40/400/600V ±(0.8%+5) DC Current 40A/400A ±(3%+5)AC Current 40A/400A ±(3%+5)Resistance 400/4K/40K/400K/4M/40M ＜1MΩ±(1.0%+5) ≥1MΩ±(2.0%+5)Frequency 10/100/1K/10K/100K/1M/10M Hz 2%Duty Cycle 500V AC/DC 2% Feature Count Display 4000 Diode test √ Continuity (audible) √ Jaw Size ≥22mmMax Conductor size ≥21mmLow battery indicator √ Adjust Zero √ Auto/Manual AutoAuto power off 30 min Data hold √ General Characteristic Power AAA 1.5V*2LCD size 46.5x24.2mm Product Size 193x61x35mm Product Net weight 173g Standard Accessories Manual,Blister card ,Test leadsSafety Rating CATⅢ 600V
