SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B
SD-07B

SD-07B

Card-size ,Manual range and 2000 counts LCD Display Test DC/AC Voltage,Resistance Diode test, Continuity,Max data hold,Low battery display

Product Line: SD-07B

LVD:

EMC:

OTHER:

  • Product description
  • parameter
  • Product parameters
  • Card-size ,Manual range and 2000 counts LCD Display
    Test DC/AC Voltage,Resistance
    Diode test, Continuity,Max data hold,Low battery display

  • Digital Multimeter SDT-07B
    Specification Range Accuracy
    DC Voltage 20V/200V
    ±(1%+5)
    AC Voltage 200V/500V
    ±(2%+10)
    Resistance 200Ω/20KΩ/2MΩ
    ±(1.5%+5)
    Feature
    Display Count   2000
    Diode test   √
    Continuity(audible)
    ＜50Ω
    Auto/Manual
    Manual
    Frequency response(Hz)
    50/60
    Low battery Display   √
    Date hold   √
    General Characteristic
    Power
    2×1.5V  LR44 Button Cell
    LCD size
    44.5×19.0 mm
    Product Size 115x58x12mm
    Product Net weight 84g
    Standard Accessories
    Battery,Test leads,Manual, Blister Card.
